Waterproof 40U Outdoor Telecom Enclosures With Remote Monitory System / Power Distribution

Name: Waterproof 40U Outdoor Telecom Enclosures With Remote Monitory System Power Distribution
Brand: ESTEL
Price: 1 USD

China Waterproof 40U Outdoor Telecom Enclosures With Remote Monitory System / Power Distribution wholesale

Brand Name : ESTEL

Model Number : ET9090210-40U

Certification : ISO9001, CE, RoHs

Place of Origin : China

MOQ : 1 Set

Price : Negotiation

Payment Terms : L/C, Western Union, T/T

Supply Ability : 5000 pcs/month

Delivery Time : 3-4 weeks

Packaging Details : Wooden Case

External Dimension : 900*900*2100mm

Internal Dimension : 19inch 40U

Material : Galvanized steel

Heat Insulation : 20mm PEF

Cooling : 1500W cooling capacity

Integrated Accessories : PDU, EMS, sensors

Contact Now

Waterproof 40U Outdoor Telecom Cabinet With Remote Monitory System And Power Distribution

1. Outdoor Telecom Cabinet Features

Waterproof, dust proof:
Sealed by import seal belt, waterproof design and air filter instrument realize the efficient protection,IP 55
Galvanized steel
Anti-theft three point lock
The cabinet includes 19” standard installation rack.
The cabinet cooling uses 220AC air conditioner cooling system
Including -48VDC illumination lamp.
The layout of the cabinet is reasonable, which will facilitate cable access, fixing and grounding.
At the bottom of the cabinet, there are entrance holes individually for power cable, signal cable and optical cable.

2. Outdoor Telecom Cabinet Standard Compliance

Standard	Description
GB/T 17626.7-1998	Electromagnetic compatibility
GB4706.1	Safety of household appliance and electrical appliance with similar use.
GB4798.1	Environmental conditions existing in the application for electric and electronic products - storage
GB4798.2	Environmental conditions existing in the application for electric and electronic products - transportation
GB4798.3	Environmental conditions existing in the application for electric and electronic products - usage

3. Technical Parameters

Item	Type	Technical Parameter
Structure	Dimension	External Dimension: WDH 9009002100mm Internal Dimension: WDH 8008001800mm
	Layout	1 compartment
	Equipment Installation Method	19” rack, 40U
	Door	With one front door, and three point lock for outdoor cabinet (support padlock)
	Material	Galvanized steel, single wall with insulation
	Heat Insulation	20mm PEF
	Ingress Protection	IP55
Temperature Control	Cooling	Air conditioner and fan
Lighting	LED lamp	LED lamp
Temperature	Temperature	Working Temperature: -40°C ~ +55°C
		Storage Temperature: -50°C ~ + 70°C
		Transport Temperature: -50°C ~ +70°C
Humidity	Relative Humidity	5% ~ 100%
Pressure	Air Pressure	62kpa ~ 101kpa (similar to 0m ~ 5000m altitude)
Radiation Intensity	Solar Radiation Intensity	1120 × (1±5%) W/m2

4. Accessories List

No.	Item	Quantity	Unit	Specs
1	Outdoor Telecom Cabinet	1	Set	(1) External Dimension: WDH 9009002100mm (2) One compartment: 19” 40U (3)With one front door, and three point lock for outdoor cabinet (support padlock) (4) Material: galvanized steel, single wall with insulation
2	Air Conditioner	1	Set	Cooling capacity: 1500W, Power Supply: AC220V, 50Hz
3	Auxiliary Direct Ventilation Fans	2	PC	AC220V
4	Environment Monitoring Unit	1	Set	1U, AC220V, support SNMP communication
5	Water Sensor	1	PC
6	Smoke Sensor	1	PC
7	Temperature and Humidity Sensor	1	PC
8	Door Sensor	1	PC
9	LED Lamp	1	PC	AC220V
10	Power Distribution Unit	1	Set	Grade B Lightning Proof AC Input: 63A/2P 1; AC Output: 16A/1P4; DC Output: 16A/1P*4 Input Voltage: AC220V.
11	Package	1	Set	Wooden Case

5. Various cooling system for your choice

Natural ventilation cooling system
DC/AC Air conditioner cooling system
Heat exchanger cooling system
Fan cooling system
TEC cooling system

6.Packing

Waterproof 40U Outdoor Telecom Enclosures With Remote Monitory System / Power Distribution
